Bauxite crusher
Feed size :400-600mm. Production capacity :3-500T / h.
Crushing materials: limestone, calcium carbide, calcium carbide slag, shale, basalt, river gravel, bluestone, iron ore, copper, steel slag, etc. Applications: Mining, metallurgy, building materials, road, water, chemicals and a variety of ores, and many other industries. Was the highest compressive strength of crushed material is 320Mpa.
Bauxite ore is also called alumina or bauxite, the main ingredient is alumina, alumina hydrate containing impurities, which is an earthy minerals. White or off-white, iron and brownish yellow or light red. Density 3.9 ~ 4g/cm3, hardness of 1 to 3, opaque, brittle. Extremely difficult to melt. Insoluble in water, soluble in sulfuric acid, sodium hydroxide solution. Mainly used for aluminum, Built refractory.
Variety of Bauxite
Bauxite crusher Introduction:
Yifan Machinery production of bauxite crusher is widely applied in mining, metallurgy, construction, highway, railway, water conservancy and chemical industry and many other industries to deal with a large particle size, the compressive strength does not exceed what a 320Mpa the ores and rocks of coarse crushing or in crushed operations.
Bauxite crushers - jaw crusher
Bauxite crusher works:
When bauxite crusher work, the motor is driven by high-speed rotation of the rotor in the crushing cavity. Material from the upper to the inlet to the machine by the high-speed movement of the hammer blow, impact, cutting, grinding and grinding. In the lower part of the rotor, with sieve plate, the crushed material is less than the sieve size sieve discharged through the sieve size larger than the coarse fraction retention continues to be a hammer blow and grinding in the sieve, and finally through the sieve from the plane.
Bauxite crushers advantage Features:
[1] The crushing high efficiency, low running costs
[2] The particle size uniformly, large output
[3] Less dust pollution, easy maintenance
[4] Low noise, energy saving
Zhengzhou Yifan Machinery Co., Ltd. is China's leading supplier of crushing and screening equipment.Yifan Machinery is a professional the bauxite crushing equipment manufacturers, Yifan Machinery adopts the most advanced international crushing technology and manufacturing standards specifically developed efficient bauxite crusher. If you want to know more about bauxite crusher For more information you can contact our online customer service or leave us a message below, every day we will see a message and the first time to contact customers with the latest discount offer information.
Hot Keywords: bauxite crusher,bauxite crusher price, bauxite production line
Bauxite crusher Technical Data:
Product Name | feed size( ㎜ ) | Max feed size( ㎜ ) | Adjustment range of discharge port( ㎜ ) | Processing capacity(m3/h) | Motor(Kw) | Weight(t) |
PE-250×400 | 250×400 | 210 | 20-60 | 3-13 | 15 | 2.8 |
PE-400×600 | 400×600 | 340 | 40-100 | 10-40 | 30 | 6.5 |
PE-500×750 | 500×750 | 425 | 50-100 | 28.5-62.5 | 55 | 10.8 |
PE-600×900 | 600×900 | 500 | 65-160 | 30-75 | 55-75 | 15 |
PE-750×1060 | 750×1060 | 630 | 80-200 | 80-160 | 90-110 | 28.9 |
PE-870×1060 | 870×1060 | 750 | 170-270 | 145-235 | 90-110 | 29.5 |
PE-900×1200 | 900×1200 | 750 | 100-200 | 100-240 | 110-132 | 49 |
PE-1000×1200 | 1000×1200 | 850 | 200-280 | 190-275 | 110-132 | 51 |
PE-1200×1500 | 1200×1500 | 1020 | 150-300 | 250-500 | 200 | 88.5 |
PEX-150×750 | 150×750 | 120 | 10-40 | 5-16 | 15 | 2.5 |
PEX-250×1000 | 250×1000 | 210 | 25-60 | 10-30 | 30-37 | 6.6 |
PEX-250×1200 | 250×1200 | 210 | 25-60 | 10-31.5 | 37 | 7 |
PEX-300×1300 | 300×1300 | 250 | 20-90 | 12.5-53 | 75 | 12 |
Dimensions(mm):
Product Name | A | B | C | D | E | F | G | H | I |
PE-250×400 | 1315 | 938 | 554 | 890 | 812 | 1450 | 750 | 220 | 735 |
PE-400×600 | 1677 | 1079 | 640 | 1190 | 897 | 1709 | 964 | 295 | 1125 |
PE-500×750 | 1906 | 1346 | 820 | 1270 | 1200 | 1890 | 1370 | 435 | 1185 |
PE-600×900 | 1840 | 1380 | 960 | 1540 | 1515 | 2305 | 1590 | 390 | 1505 |
PE-750×1060 | 2540 | 1840 | 1140 | 1800 | 1600 | 2740 | 1940 | 620 | 1780 |
PE-870×1060 | 2556 | 1840 | 1140 | 1800 | 1600 | 2860 | 2060 | 620 | 1780 |
PE-900×1200 | 3000 | 1976 | 1228 | 2135 | 1800 | 3335 | 2155 | 830 | 2110 |
PE-1000×1200 | 3000 | 1976 | 1228 | 2135 | 1800 | 3435 | 2255 | 830 | 2110 |
PE-1200×1500 | 3152 | 2352 | 1416 | 2410 | 2285 | 4618 | 3040 | 1100 | 2410 |
PEX-150×750 | 1516 | 1188 | 790 | 625 | 800 | 1250 | 588 | 190 | 470 |
PEX-250×1000 | 1992 | 1500 | 1010 | 930 | 900 | 1530 | 905 | 330 | 850 |
PEX-250×1200 | 2192 | 1700 | 1220 | 930 | 1000 | 1565 | 905 | 330 | 850 |
PEX-300×1300 | 2320 | 1840 | 1320 | 1110 | 1225 | 1750 | 1170 | 430 | 1020 |
